Zip Screen Inspection Machine

Product Overview

The RIDONG Zip Screen Inspection Machine is a turnkey fabric quality-control solution designed for zip screens, roller blinds, outdoor-shading fabrics, and technical textiles. It combines automatic cloth feeding, surface-defect detection, and tension-controlled cloth rolling into a single, software-driven production line.

The operator loads the fabric roll onto the unwinding station, sets the inspection parameters through the HMI control panel, and the system handles the rest. Fabric is fed through the inspection zone at a constant, digitally controlled speed while the inspection unit highlights surface defects such as holes, stains, yarn breakage, weaving flaws, color shading, and contaminations. The same line then rewinds the inspected fabric onto a finished roll with consistent tension — ready for the next cutting, slitting, or packaging process.

Built on servo-driven unwinding, high-precision digital tension control, and PLC-based automation, the machine delivers consistent inspection quality on every meter of fabric, eliminating the variability and fatigue of manual visual inspection. The modular design allows optional add-ons such as defect-marking devices, length counters, edge-trimming knives, and automatic roll-changing units.

Key Features

• One-Line Integrated Workflow — Automatic unwinding, defect inspection, and tension-controlled rewinding in a single continuous line; no manual transfer between stations.
• High-Precision Digital Tension Control — Servo-driven unwinding and rewinding keep fabric flat and wrinkle-free throughout the inspection process.
• Stable, Stepless Speed Adjustment — Digital frequency converter enables smooth, programmable speed control matched to different fabric types and operator preferences.
• Vision-Assisted Surface Inspection — The inspection zone highlights surface defects such as holes, stains, yarn breaks, color shading, weaving flaws, and foreign contamination.
• Automatic Length Counting — Integrated encoder provides real-time fabric length measurement and roll-completion signaling for predictable production planning.
• Industrial-Grade Build Quality — Heavy-duty steel frame, precision-ground rollers, and CE-compliant electrical components designed for 24/7 continuous operation.
• Full Customization Available — Working width, line speed, roll diameter, and additional modules are all adjustable to fit your factory layout and throughput targets.

Technical Specifications

Exquisite Craftsmanship

• Heavy-Duty Welded Steel Frame — Laser-cut, robot-welded, and stress-relieved to keep machine geometry stable under continuous high-speed operation.
• Precision-Ground Rollers — Hard-anodized aluminum and rubber-coated rollers with surface roughness Ra ≤ 0.8 μm to avoid fabric scratching.
• CE-Compliant Electrical Components — Schneider / Siemens / Delta parts, surge-protected and EMC-tested for industrial environments.
• Anti-Rust Surface Treatment — Powder-coated or galvanized critical surfaces, suitable for humid environments and overseas shipping.
• Modular Mechanical Design — Quick-change roller sets and modular stations reduce changeover time between fabric types.

Target Applications & Industries

• Zip Screen & Outdoor Shading Fabric Manufacturing
• Roller Blind & Blackout Fabric Production
• Technical Textile & Industrial Fabric Processing
• Awning, Tarpaulin & Sun-Protection Fabric Mills
• Apparel & Home-Textile Quality-Control Lines
• Large-Scale Fabric Warehouses & Distribution Centers

Compatible Fabrics

• Zip-screen fabric & outdoor-shading cloth
• Roller-blind fabric & sunscreen fabric
• PVC-coated polyester & fiberglass fabric
• Technical textile & coated fabric
• Sun-protective mesh & insect screen

Frequently Asked Questions

Q1: What is the maximum working width of the inspection machine?

A: The standard working width is 6,000 mm. Widths from 7,000 mm to 8,000 mm are available on request.

Q2: Can the line speed be adjusted?

A: Yes. The line uses a digital frequency converter for stepless speed adjustment, typically 5–30 m/min depending on fabric type.

Q3: What kinds of defects can the inspection zone detect?

A: The illuminated inspection zone supports operator identification of holes, stains, yarn breaks, color shading, weaving flaws, oil contamination, and foreign fibers. An automatic defect-marker is available as an optional add-on.

Q4: Is the machine size customizable?

A: Yes. Working width, line length, machine height, roll diameter, and all optional modules are fully customizable based on your factory layout and production targets.

Q5: What after-sales support does RIDONG provide?

A: Factory-direct sales, on-site installation supervision, free operator training, sample validation before final acceptance, and a 12-month warranty with lifetime technical support. Service network covers 80+ countries.

Q6: What are the power and air-supply requirements?

A: 380V,220V,110V / 50–60 Hz three-phase power. If pneumatic modules are installed, a 0.4–0.6 MPa clean compressed-air supply is required.

Q7: How many operators are needed per shift?

A: One operator per shift is sufficient for standard operation, including loading, parameter setting, monitoring, and roll doffing.
